Adjustable relay SSR-25VA solid state module

SSR-25VA solid state module
Brand
NQQK

 Adjustable relay SSR-25VA solid state module

Product Description

 WE ARE FACTORY. SO WE CAN OEM ANY BRAND.

Introduction:

Solid state relay (SSR) is an electronic switching device that switches states when an external voltage is applied along its n-type and p-type junctions. SSR has a small control signal that controls a larger load current or voltage. It consists of a sensor which responds to an appropriate input (control signal), a solid-state electronic switching device which switches power to the load circuitry, and some coupling mechanism to enable the control signal to activate this switch without mechanical parts. The relay may be designed to switch either AC or DC to the load. It serves the same function as an electromechanical relay, but has no moving parts.

Specifiction classification SSR-10VA   SSR-60VA     SSR-25VA    SSR-80VA  SSR-40VA
Outine Dimension(mm) 62.0Lx44.0Wx23.0H
Load Current 10A,15A,25A,40A,60A,80A
Load Voltage 24~380VDC(Basic model)
Control Voltage VR:350KΩ/110VAC     500KΩ/220VAC
Control Current /
On Voltage ≤1.5V
Off leakage Current ≤2mA
On-off time /
Dielectric Strength 2500VAC Importing exporting beef one heat release boards
Insulation Resistance 1000MΩ/500VDC
Ambient Temperature -30~+75°C
Mounting Mthods Bolt Fixing
Working Station Indicator /
Weight 132g



 1 SSR-25VAC 380VAC.JPG2  SSR-25VAC 380VAC.JPG3  SSR-25VAC 380VAC.JPG4 SSR-25VAC 380VAC.JPG5 SSR-25VAC 380VAC.JPG







Trade Information

Trade Terms FOB ,CIF ,CFR,EXW,DDP
Payment terms T/T,L/C,Western union,Paypal,Escrow,MoneyGram
Payment conditions 30% deposit in advance,70% balance before shipping.
Delivery time 3-7working days after deposit,2-4 working days for inventory
Packing Neutral carton,Wooden case for large size
Shipping By sea,by air and by express delivery
