High Power Temperature Regulator 120A 15KW Solid State 220v Single Phase Electronic SCR Regulator

Model
SSR-120VA
Brand
NQQK
High Power Temperature Regulator 120A 15KW Solid State 220v Single Phase Electronic SCR Regulator
Product Description
product name
Solid state regulator regulator
Product number
SSR-120A (Har
Contact Now
High Power Temperature Regulator 120A 15KW Solid State 220v Single Phase Electronic SCR Regulator
High Power Temperature Regulator 120A 15KW Solid State 220v Single Phase Electronic SCR Regulator High Power Temperature Regulator 120A 15KW Solid State 220v Single Phase Electronic SCR Regulator High Power Temperature Regulator 120A 15KW Solid State 220v Single Phase Electronic SCR Regulator

High Power Temperature Regulator 120A 15KW Solid State 220v Single Phase Electronic SCR Regulator

Product Description

product name Solid state regulator regulator
Product number SSR-120A (Hardcover)
Input voltage AC220V
The output voltage 0-220V adjustable (must be under load condition)
Maximum power 15000W (full power)
High pressure range 0-220V stepless adjustable (must be under load conditions) straight forward to achieve step down to 0V, boost from 0V
Rated current 120A
Features There is no isolation between the control terminal and the output terminal. Only the occasions where the manual control of the resistive load is not required are applied, and the sensitive applications such as inductive loads are used with caution.
Executive standard CE



Enhanced pressure regulator module application range: Heating: various heating furnaces, injection molding equipment, thermoplastic molding, textile equipment, infrared heating, power distribution system, drying system, tool control speed: brush motor speed, angle grinder, Marble machine, polishing machine, engraving machine, electric drill, etc., can book a variety of external control signals: 0-5V, 0-10V, 4-20mA multi-signal (reservation) machine small size, light weight, fast response, no mechanical mechanism Features.
